เครื่องดัดไฟฟ้าไฮดรอลิกคืออะไร? มันทำงานอย่างไร?

An electro-hydraulic bending machine is a specialized machine for bending metal pipes. It is widely used in industries such as automotive, aerospace, construction, and energy, especially in applications requiring precise bending of pipes to accommodate different shapes and specifications. Compared to traditional manual or mechanical bending equipment, electro-hydraulic bending machines have become indispensable equipment in pipe processing due to their high efficiency, high precision, and automation.

1. What is an Electro-Hydraulic Bending Machine ?

An electro-hydraulic bending machine is a device that uses an electro-hydraulic control system to drive a hydraulic device to bend pipes. It combines the advantages of electrical control and hydraulic technology, featuring high precision, high efficiency, and a high degree of automation, enabling precise bending of various pipe materials. Compared to traditional mechanical bending machines, the hydraulic system of an electro-hydraulic bending machine provides stronger driving force and more precise control, allowing it to handle more complex bending tasks.

Electro-hydraulic pipe bending machines can adapt to the processing needs of different types of pipes (such as steel pipes, stainless steel pipes, copper pipes, aluminum pipes, etc.) and can bend pipes to different angles and radii, meeting the needs of various engineering and manufacturing fields.

2. Working Principle of an Electro-Hydraulic Bending Machine

The working principle of an electro-hydraulic bending machine mainly includes several parts such as electrical control, hydraulic drive, and bending process. The following is its basic working process:

(1) Electrical Control System
The electro-hydraulic bending machine is equipped with a precise electrical control system, responsible for accurately adjusting the hydraulic system. The control system sets bending parameters, such as bending angle, bending radius, and bending speed, through numerical control technology (CNC) or a manual operation interface. The operator can input parameters according to process requirements, and the system automatically adjusts the hydraulic drive part according to the set values ​​to complete the bending operation of the pipe.

(2) Hydraulic Drive System
The hydraulic system of the electro-hydraulic bending machine is its core drive part. The hydraulic system generates strong pressure through components such as hydraulic pumps, hydraulic cylinders, and valves to push the pipe to bend. The hydraulic system can provide a stable high-pressure oil flow to ensure the stability and high precision of the pipe bending process. Hydraulic Pump: The hydraulic pump provides hydraulic power, driving hydraulic oil into the cylinder to generate sufficient bending pressure.
Hydraulic Cylinder: The hydraulic cylinder is the power source of the electro-hydraulic pipe bending machine. Through the propulsion of the oil flow, it converts hydraulic energy into mechanical energy, driving the bending tool to bend the pipe.
Hydraulic Valve: The hydraulic valve controls the direction, pressure, and flow rate of the hydraulic oil, precisely adjusting the distribution of oil flow during bending to ensure bending accuracy and speed.

(3) Bending Process
The bending process of an electro-hydraulic pipe bending machine typically uses molds, rollers, or forming devices to bend the pipe along a specified trajectory using a hydraulic system. The equipment controls the bending angle, radius, and shape by changing the pressure and oil flow of the hydraulic system.
Molds: Electro-hydraulic pipe bending machines are usually equipped with different types of bending molds to support and fix the pipe, ensuring that the shape and size of the pipe meet design requirements during bending.
Rollers: Some electro-hydraulic pipe bending machines use a roller structure, achieving smooth bending through the cooperation of multiple rollers.

3. Advantages of Electro-Hydraulic Bending Machines

Electro-hydraulic bending machines, due to their high efficiency, precision, and automation, have gradually replaced traditional mechanical bending equipment, becoming the preferred tool for many production lines and manufacturing plants. Their main advantages include:

(1) High Precision and High Quality
Through a precise electrical control system and hydraulic system, electro-hydraulic bending machines maintain high precision in the angle, radius, and shape of the pipe during the bending process. Especially for industries requiring high precision and high quality, such as aerospace and automotive, electro-hydraulic bending machines can provide stable and reliable bending results.

(2) Improved Production Efficiency
Electro-hydraulic bending machines can complete pipe bending operations in a shorter time. Compared to traditional manual or mechanical operations, electro-hydraulic bending machines have a higher degree of automation, significantly improving production efficiency and reducing labor costs and time.

(3) Wide Applicability
Electro-hydraulic pipe bending machines can bend pipes made of various materials (such as steel, copper, stainless steel, aluminum, etc.) and can handle pipes of different specifications and shapes. Therefore, they are widely used in many industries, including automotive manufacturing, petrochemicals, construction, and aerospace.

(4) Reduced Material Waste
Due to the precise control of the electro-hydraulic pipe bending machine, the deformation of the pipe during bending is minimal, minimizing material waste. This is particularly important for industries producing high-value, high-cost materials.

(5) Simple Operation and High Degree of Automation
Electro-hydraulic pipe bending machines are typically equipped with a CNC system, making operation simple and user-friendly. The operator only needs to input the bending parameters, and the system can automatically complete the pipe bending. This greatly reduces the difficulty of operation and the possibility of human error.

With its high efficiency, high precision, and automation, the electro-hydraulic pipe bending machine has become an indispensable piece of equipment in the pipe processing field. It not only improves production efficiency and reduces manual operation but also ensures the bending quality and stability of the pipes. With the continuous advancement of technology, electro-hydraulic pipe bending machines will play a greater role in more fields, promoting technological upgrades and productivity improvements across various industries.
